-About Aerial Platform Truck:
Our unique design operation system of three-section telescopic boom could help the worker stable operation in the air.
The main purposes are: maintaining, installing, cleaning, camera shooting, ship bulding, chemical industry, electric power, pruning and streetlight changing etc. in the air from 8m to 24m height.
-Characteristics:
1. The boom is made of high-strength steel plate HQ60/5mm welded and formed, and the outriggers are made of low-alloy Q345 profile, with no welds around, beautiful appearance, strong force and high strength;
2. The cylinder drive chain drives the telescopic arm to expand and contract synchronously, which is stable and reliable;
3. H-shaped outriggers have good stability, the outriggers can be operated at the same time or individually, and the operation is flexible and can adapt to a variety of working conditions;
4. The turntable rotates in two directions at 360°, and adopts an advanced worm and worm integrated closed reduction mechanism; (with self-lubricating and self-locking functions)
5. Automatic control by controller, with display screen, set protection mode to limit amplitude, safe and reliable;
6. Two-position operation of getting off the car and the hanging basket, electro-hydraulic proportional speed regulation;
7. Getting off and getting on is interlocked, the operation is safe and reliable;
8. The hanging basket adopts advanced static hydraulic automatic leveling, which is more stable and reliable;
9. There are engine start and stop switches for getting off the car and the hanging basket, which is easy to operate and save fuel;
Product Parameters
| Vehicle Description |
| Vehicle model | Platform Truck | Overall dimensions (mm) | 7640×1990×3150 |
| GVW (kg) | Appro×6800 | Operational height (m) | 16 |
| Mass in working order (kg) | Appro×5185 | Max. Speed (km/h) | 95 |
| Chassis Description |
| Cab | Crew cab with A/C |
| Allowable person in cab | 5 |
| Wheel base (mm) | 3360 |
| Number of axles | 2 |
| Axle | Front axle | 2000 |
| Rear axle | 4800 |
| Operation control system | Power steering |
| Braking system | Oil brake |
| Transmission | 5-speed MSB |
| Tire specification | 7.00R16 |
| Tire quantity | 6+1 |
| Engine Description |
| Engine manufacture | ISUZU Engines |
| Engine model | 4KH1CN5HD |
| Emission standard | Euro 5 |
| Up-parts Description |
| Bucket |
| Max. working height | 14m |
| Max. working radius (m) | 7 |
| Working height at max. radius (m) | 9 |
| Working radius at max. height (m) | 2 |
| Rated loading (kg) | 200 |
| Type | Three section , articulated |
| Rotation Angle | 360 |
| Thickness of boom plate | 4mm |
| Max. rising angle of upper and lower boom | 70/70 |
| Max. rising angle of small boom | 90 |
| Outrigger |
| Type | H |
| Vertical Breadth (mm) | 3300 |
| Horizontal Breadth (mm) | 3380 |
| Adjustment | Adjusted separately |
| Hook |
| Max. Lifting height (m) | 8.4 |
| Max. Lifting Weight (kg) | 1000 |
